Taper shank drills Bohrcraft 1450 according to DIN 345 HSS

Bohrcraft 1450 taper shank drill, DIN 345 standard, made from HSS high-speed steel, is a specialized drill bit designed for demanding industrial drilling tasks. Manufactured from high-speed steel (HSS), this drill offers both durability and precision. Its double-ended design and split point geometry provide excellent centering and reduced walking, making it suitable for thin-walled materials where accuracy is essential. The 118° point angle further enhances its ability to penetrate metal surfaces efficiently.

These taper shank drills are compliant with DIN 345 standards, ensuring compatibility and reliability in professional environments. The available diameter range from 2.00 mm to 6.00 mm covers a wide spectrum of drilling needs. With overall lengths (L1) between 43 mm and 66 mm and working lengths (L2) from 13 mm to 19 mm, these drills are versatile for various setups. Their robust construction allows for repeated use in sheet metal, flat steel, and profile applications without compromising performance.

The split point 1412 C design minimizes burr formation and heat buildup, extending tool life and improving hole quality. These features make the Bohrcraft 1450 series a dependable choice for workshops and production lines requiring consistent, high-quality results. The drills are especially suited for thin materials, reducing the risk of deformation or damage during operation.

Bohrcraft 1450 Taper Shank Drill, DIN 345 Standard, HSS High-Speed Steel

Technical Specifications

The Bohrcraft 1450 taper shank drills are engineered for precision and longevity. Their high-speed steel composition ensures resistance to wear and heat, while the split point tip delivers clean, accurate starts. The double-ended design allows for extended use, maximizing value and reducing downtime in industrial settings.

• Material: High-speed steel (HSS)
• Standard: DIN 345
• Design: Double-ended
• Point angle: 118°
• Split point: 1412 C
• Diameter range: 2.00 mm – 6.00 mm
• Overall length (L1): 43 mm – 66 mm
• Working length (L2): 13 mm – 19 mm

Each drill is manufactured to strict tolerances, ensuring consistent hole diameters and minimizing runout. The split point geometry is particularly effective for thin materials, providing a stable entry and reducing the need for pilot holes. These features contribute to increased productivity and reduced tool changes.

Common Applications

Bohrcraft 1450 taper shank drills are widely used in metalworking, fabrication, and maintenance operations. Their ability to drill cleanly through sheet metal, flat steel, and profiles makes them a preferred choice for professionals in automotive, construction, and manufacturing sectors.

• Sheet metal fabrication
• Flat steel drilling
• Profile and structural steel work
• General industrial maintenance

The drills are also suitable for use in automated production lines and manual workshop setups, offering flexibility across different drilling machines equipped with taper shank holders.

Catalog/Manual Technical Content

[Catalog: bohrcraft-katalog-2024-de-gb-noted-p0096.pdf]

• Double ended drills HSS-G fully ground, split point
• Especially designed for drilling thin materials like sheet metal, flat-steel, profiles
• Point angle: 118° (NORM G)
• Split point: 1412 C
• Diameter: 2.00 mm – 6.00 mm
• Overall length (L1): 43 mm – 66 mm
• Working length (L2): 13 mm – 19 mm

The catalog details the technical parameters and highlights the suitability of these drills for thin-walled materials. The product is presented with clear dimensional data and intended use cases, supporting informed selection for industrial buyers.
